New Wacker Neuson GP5500A Generator

New Portable generator power designed for construction applications or anywhere high performance, reliable power is needed.

Item Number 5100070505

Designed for construction, rental and other demanding applications, these quiet, high-performance, portable generators deliver unmatched tool starting and voltage regulation in a rugged compact package. Excellent for powering single or multiple tools on an entire job site or as emergency or standby power. Ideal for powering high starting amperage tools such as compressors, grinders, fusion welders as well as all your Wacker Neuson electric power tools.  Unique step-start generator technology with Automatic Voltage Regulation (AVR) Automatic Voltage Regulation (AVR) and separate excitation winding delivers best in class tool starting and voltage regulation.  Proven Honda GX340 engine with low oil shutdown. Tried and true Honda engine for reliable starting and longevity. Fully compliant with the latest EPA evaporative emissions regulations. Robust, powder coated steel frame with dual cross-member support. High impact polyethylene fuel tank and heavy duty shock-mounting combine to provide outstanding impact protection.

Technical Data
■ Mechanical Details
Length 523.0 mm
Width 698.0 mm
Height 612.0 mm
Operating weight 78.9 kg
Dry Weight 57.2 kg
■ Generator
Insulation class H
Output frequency 60.0 Hz
Efficiency factor 1~ 1.0 cos φ
Phase 1.0 ~
Voltage accuracy 6.0 %
Generator specification Brushless
Voltage 1~ 120.0 V
Power rating max. 5,500.0 W
Continuous Output 5,000.0 W
■ Environment Data
Sound level LpA 74.0 dB(A)
■ Electrical System
Circuit Breaker Amperage AC 21.0 A
Breaker Switch On/Off 1 Pole
Receptacle Type NEMAL5-30R,TL,125V,30A
Number of Sockets 4.0
■ Operating Fluids
Fuel consumption (Prime load) 3.5 L/hr
Run Time (Prime Load) 8.5 hrs
