KEY FEATURES
• Patented cutting-deck design yields professional results.
• Hydro-Gear ZT-2800 on/48″/52″ and ZT-3100 on 60″
hydrostatic drive system delivers a smooth drive experience and
years of reliable service.
• Radius models are equipped with large, 13″ x 6.5″ pneumatic
front caster tires.
• Easy-to-use, accurate sight window-type fuel gauge is standard
on all Radius models.
• Integrated rear tow hitch standard on all Radius models.
• Easy to Service—A tools-free removable foot rest eases access
to the top-side of the cutting deck, and tool-less removable
belt shields provide easier access to belts and spindles on. The
welded jack receiver allows quick access to the underside of the
deck when combined with the optional jack.
ULTRACUT SERIES 3 DECK FEATURES
A. 5.0″ deck depth. 4-point suspension. Full-floating
B. 10-gauge steel top
C. 7-gauge steel side skirt.
D. 7-gauge steel reinforcement rings at spindle mounting
E. Radius E- & S-Series (side-discharge, excludes CA3 models)-
7.30″-diameter cutter housing contains 17mm- (.67″) diameter
spindle shaft and hex blade driver.
F. 18,500 fpm blade tip speed.
G. Patented flow-control baffles.
H. High-strength polymer belt covers standard on Radius
E-Series and S-Series
I. No-maintenance, sealed ball bearings.
J. Flexible discharge chute reduces impact damage of trees and
other obstacles.
K. Coned anti-scalp rollers
